UC Davis School of Veterinary Medicine Veterinary Genetics Laboratory

Chondrodystrophy (CDDY and IVDD Risk) and Chondrodysplasia (CDPA)

Shorter legs in dogs are explained by two retrogene insertions of functional fibroblast growth factor 4 (FGF4). FGF4 gene is involved in many biological processes including bone development.

The first insertion discovered (Parker et al 2009) is an FGF4-retrogene insertion in dog chromosome 18 (FGF4-18). This FGF4-18 insertion explains a short-legged phenotype known as chondrodysplasia (CDPA) in breeds such as Basset Hound, Pembroke Welsh Corgi, Dachshunds, West Highland White Terriers and Scottish Terriers. CDPA inheritance is considered to follow an autosomal dominant mode.

The Chondrodystrophy (CDDY) mutation was discovered by researchers in the Bannasch Laboratory at the University of California, Davis (Brown et al. 2017) as a second FGF4-retrogene insertion in dog chromosome 12. CDDY includes a short-legged phenotype and abnormal premature degeneration of intervertebral discs leading to susceptibility to Hansen’s type I intervertebral disc disease (IVDD). The intervertebral disc, which sits between vertebrae, is composed of an outer fibrous basket (annulus fibrosus) made of 70% collagen and an inner gel-like layer called the nucleus pulposus. These structures allow for flexibility of the vertebral column. In Chondrodystrophic breeds, premature calcification of the nucleus pulposus at early age (from birth to 1 year of age) results in degeneration of all discs in young dogs. These abnormal discs are predisposed to herniation into the spinal canal where the inflammation, and hemorrhage can cause severe pain and neurological dysfunction (myelopathy) termed Intervertebral Disc Disease or IVDD. IVDD has high mortality rate and high cost of surgical and medical veterinary care.

CDDY is inherited as a semi-dominant trait for height, meaning that dogs with 2 copies of the mutation are smaller than dogs with only 1 copy. With respect to IVDD, the inheritance follows a dominant mode, meaning that 1 copy of the FGF4-12 mutation is sufficient to cause disc degeneration and predispose dogs to disc herniation. Dogs that have both FGF4-12 and FGF4-18 show a more drastic reduction of leg length.

The Veterinary Genetics Laboratory offers a combined test for CDDY and CDPA for breeds that have long and short leg phenotypes. Our tests assay for the causal variants, not for linked markers, therefore the genotypes are accurate and not inferred. CDDY and CDPA occur in many breeds. Testing for these mutations can help breeders determine if CDDY is present among breeding stock and to identify dogs at risk for IVDD. In breeds where both mutations are present, breeders can benefit from test results to implement breeding strategies to reduce incidence of CDDY, while retaining the short-legged phenotype conferred by CDPA.

ORDER TEST KITS | PRICE LIST
Allow 5-10 business days for results.

Results reported as:

Chondrodystrophy (CDDY and IVDD Risk)
N/N No copies of CDDY mutation.
N/CDDY 1 copy of CDDY mutation. Dog is at risk for IVDD. Mutation causes leg shortening compared to N/N dogs. When bred to an N/N dog will produce 50% of normal sized puppies and 50% of  puppies at risk for IVDD.
CDDY/CDDY 2 copies of CDDY. Dog is at risk for IVDD. Mutation causes leg shortening compared to N/N dogs. Will produce 100% of puppies with shorter legs at risk for IVDD.

Chondrodysplasia (CDPA)
N/N No copies of CDPA mutation.
N/CDPA 1 copy of CDPA. Mutation causes leg shortening compared to N/N dogs.
CDPA/CDPA 2 copies of CDPA. Mutation causes leg shortening compared to N/N dogs.

The CDDY variant has been found in many breeds such as Alpine Dachsbracke, American Cocker Spaniel, Australian Shepherd, Basset Hound, Bavarian Mountain Hound, Beagle, Bichon Frise, Boykin Spaniel, Cardigan Welsh Corgi, Cavalier King Charles Spaniel, Chesapeake Bay Retriever, Chihuahua, Chinese Crested, Clumber Spaniel, , Coton de Tulear, Dachshund, Dandie Dinmont Terrier, Danish Swedish Farmdog, English Springer Spaniel, Entlebucher Mountain Dog, French Bulldog, German Hound, Havanese, Jack Russell Terrier, Maltese, Nova Scotia Duck Tolling Retriever, Pekingese, Pembroke Welsh Corgi, Pinscher (Miniature), Poodle (Miniature and Toy), Poodle (Standard), Portuguese Water Dog, Pug, Rat Terrier, Russian Tsvetnaya Bolonka, Schweizer Laufhund, Schweizerischer Niederlaufhund, Scottish Terrier, Sealyham Terrier, Shih Tzu, Skye Terrier, and Yorkshire Terrier. This is not a complete list of breeds.

A comprehensive study was recently completed by Batcher and colleagues 2019 to investigate the breed distribution. (https://doi.org/10.3390/genes10060435) In addition, the VGL has conducted a study of nearly 4000 dogs across 35 breeds to identify allele frequencies and make recommendations on testing. These data can be found in the following table, we will update this table periodically as more dogs are tested.

BreedTotal Dogs TestedAllele Frequency
Akita: Japanese type120.000
Alaskan Klee Kai100.000
Alaskan Malamute110.000
American Hairless Terrier140.000
Australian Shepherd100.100
Beagle1410.993
Black Russian Terrier200.000
Boston Terrier120.000
Boykin Spaniel1290.554
Cardigan Welsh Corgi390.769
Cavalier King Charles Spaniel211.000
Chesapeake Bay Retriever350.086
Chinese Crested310.435
Coton de Tulear6560.425
Dachshund480.979
Dalmatian650.000
Doberman Pinscher370.000
English Bulldog520.000
English Springer Spaniel230.391
French Bulldog4770.892
German Shepherd130.000
German Shorthaired Pointer270.000
Great Dane150.000
Havanese560.071
Labrador Retriever950.000
Miniature American Shepherd110.091
Nova Scotia Duck Tolling Retriever15080.358
Pembroke Welsh Corgi300.867
Poodle, Miniature100.750
Poodle, Standard570.053
Pug1430.003
Rat Terrier760.033
Sealyham Terrier190.658
Shiba Inu150.000
Weimaraner330.000
Total3951

Recommendations on Testing: For those breeds in which CDDY has been documented to segregate, in other words, both the CDDY allele and the normal allele are present in the breed, genetic testing is recommended. The results of this test can assist in breeding decisions and should be shared with the animal’s veterinarian to assist in clinical decisions. The CDDY allele has been found to be present in mixed breed dogs and therefore testing is recommended for these animals as well. For breeds where the CDDY allele is fixed in the population, in other words only the CDDY is present or allele frequency is 1.0, genetic testing for CDDY is not necessary, in these cases it is reasonable to assume that all dogs in that breed will be homozygous for CDDY (CDDY/CDDY).

For more information on recommendations on genetic testing and counseling, please see the article written by Drs. Bannasch and Bellone.

References:

Parker HG, VonHoldt BM, Quignon P, Margulies EH, Shao S, Mosher DS, Spady TC, Elkahloun A, Cargill M, Jones PG, Maslen CL, Acland GM, Sutter NB, Kuroki K, Bustamante CD, Wayne RK, Ostrander EA. 2009. An expressed fgf4 retrogene is associated with breed-defining chondrodysplasia in domestic dogs. Science 325(5943):995-8. doi: 10.1126/science.1173275.

Brown EA, Dickinson PJ, Mansour T, Sturges BK, Aguilar M, Young AE, Korff C, Lind J, Ettinger CL, Varon S, Pollard R, Brown CT, Raudsepp T, & Bannasch DL. (2017) FGF4 retrogene on CFA12 is responsible for chondrodystrophy and intervertebral disc disease in dogs. PNAS 114 (43) 11476-11481. doi: 10.1073/pnas.1709082114.

Batcher, K.; Dickinson, P.; Giuffrida, M.; Sturges, B.; Vernau, K.; Knipe, M.; Rasouliha, S.H.; Drögemüller, C.; Leeb, T.; Maciejczyk, K.; Jenkins, C.A.; Mellersh, C.; Bannasch, D. Phenotypic Effects of FGF4 Retrogenes on Intervertebral Disc Disease in Dogs. Genes 2019, 10, 435. doi: 10.3390/genes.10060435

Murphy, B.G.; Dickinson, P.; Marcellin-Little, D.J.; Batcher, K.; Raverty, S.; Bannasch, D. Pathologic Features of the Intervertebral Disc in Young Nova Scotia Duck Tolling Retrievers Confirms Chondrodystrophy Degenerative Phenotype Associated With Genotype. Veterinary Pathology 2019, 030098581986873. doi: 10.1177/0300985819868731
